Y CPU Units

XA CPU Units

X CPU Units

12 inputs,
8 outputs
Two line-driver inputs
Two line-driver outputs

24 inputs,
16 outputs, 4 analog inputs,
2 analog outputs

24 inputs,
16 outputs

Program capacity

20K steps

Data memory
capacity

32 Kword

High-speed
processing

0.1 碌s/LD instruction, 0.3 碌s/MOV instruction

Counters

1 MHz (single-phase), 500 kHz
(differential phases) for two axes
(line driver outputs), 100 kHz (singlephase),
50 kHz (differential phases)
for two axes (four axes tota

100 kHz (single-phase),

50 kHz (differential phases)

Pulse outputs

1 MHz for two axes
(line driver outputs),
100 kHz for two axes
(four axes total)

100 KHz for four axes

(only for transistor outputs)

Serial
communications

Two serial ports can be added as options
(either RS-232C or RS-422A/485 Option Boards).

Ethernet
communications

Two Ethernet ports can be added as an option.
When using CP1W-CIF41 Ver.1.0, one Ethernet port can be added.

Built-in analog I/O

-

4 analog inputs and
2 analog outputs
(resolution: 6,000 or 12,000)

-

Expansion Unit

MAX 7 Unit

MAX 7 Unit

MAX 7 Unit

CP1H

CP1H-Y20DT-D

CPU 20K Step; 12DI/8DO DC power supply,transistor (sinking) outputs

CP1H-X40DR-A

CPU 20K Step; 24DI/16DO AC power supply,relay outputs

CP1H-X40DT-D

CPU 20K Step; 24DI/16DO DC power supply,transistor (sinking) outputs

CP1H-X40DT-A

CPU 20K Step; 24DI/16DO AC power supply,transistor (sinking) outputs

CP1H-X40DR-D

CPU 20K Step; 24DI/16DO DC power supply,relay outputs

CP1H-XA40DR-A

CPU 20K Step; 12DI/8DO/4AI/2AO AC power supply,relay outputs

CP1H-XA40DT-D

CPU 20K Step; 12DI/8DO/4AI/2AO DC power supply,transistor (sinking) outputs

CP1H-XA40DT-A

CPU 20K Step; 12DI/8DO/4AI/2AO AC power supply,transistor (sinking) outputs

CP1H-XA40DR-D

CPU 20K Step; 12DI/8DO/4AI/2AO DC power supply,relay outputs
