Omron Programmable Relay ZEN PLC
Programmable Relay ZEN ZEN PLC
The ZEN provides relays, timers, counters, and time switches all in one Unit. Ladder programming is possible using only a LCD and eight operation buttons.
Even Broader Applications with Increased Functionality and Higher Precision
· Increased functionality in a compact body (70 mm wide × 90 mm high).
· Easy programming is available using the LCD and operation buttons. (See note 1.)
· This single Unit easily provides relay, timer, counter, and time switch functions.
· Expansion is easy with Expansion I/O Units, allowing up to 44 I/O points. (See note 2.)
· Economy-type and Communications-type CPU Units have been added to series.
· Improved Weekly Timers (See note 1.) Increased timing accuracy with a monthly deviation of ±15 s max. Multiple-day operation and pulse output operation have been added.
· Select from two power supply options: 100 to 240 VAC or 12 to 24 VDC
Model | Description |
ZEN Standard LCD Type (3 Expansion Module) | |
ZEN-10C1AR-A-V2 | ZEN CPU; 6DI (AC) / 4DO (Relay), 220VAC Supply with LCD Display |
ZEN-10C1DR-D-V2 | ZEN CPU; 6DI (DC) / 4DO (Relay), 24 VDC Supply with LCD Display |
ZEN-10C1DT-D-V2 | ZEN CPU; 6DI (DC) / 4DO (Transistor), 24 VDC Supply with LCD Display |
ZEN-20C1AR-A-V2 | ZEN CPU; 12DI (AC) / 8DO (Relay), 220VAC Supply with LCD Display |
ZEN-20C1DR-D-V2 | ZEN CPU; 12DI (DC) / 8DO (Relay), 24 VDC Supply with LCD Display |
ZEN-20C1DT-D-V2 | ZEN CPU; 12DI (DC) / 8DO (Transistor), 24 VDC Supply with LCD Display |
ZEN Standard LED Type without Display (3 Expansion Module) | |
ZEN-10C2AR-A-V2 | ZEN CPU; 6DI (AC) / 4DO (Relay), 220VAC Supply withoutout LCD Display |
ZEN-10C2DR-D-V2 | ZEN CPU; 6DI (DC) / 4DO (Relay), 24 VDC Supply without LCD Display |
ZEN-10C2DT-D-V2 | ZEN CPU; 6DI (DC) / 4DO (Transistor), 24 VDC Supply without LCD Display |
ZEN-20C2AR-A-V2 | ZEN CPU; 12DI (AC) / 8DO (Relay), 220VAC Supply without LCD Display |
ZEN-20C2DR-D-V2 | ZEN CPU; 12DI (DC) / 8DO (Relay), 24 VDC Supply without LCD Display |
ZEN-20C2DT-D-V2 | ZEN CPU; 12DI (DC) / 8DO (Transistor), 24 VDC Supply without LCD Display |
ZEN Standard Economy Type (can't expansion) | |
ZEN-10C3AR-A-V2 | ZEN CPU; 6DI (AC) / 4DO (Relay), 220VAC Supply with LCD Display |
ZEN-10C3DR-D-V2 | ZEN CPU; 6DI (DC) / 4DO (Relay), 24 VDC Supply with LCD Display |
ZEN-10C3DT-D-V2 | ZEN CPU; 6DI (DC) / 4DO (Transistor), 24 VDC Supply with LCD Display |
ZEN-20C3AR-A-V2 | ZEN CPU; 12DI (AC) / 8DO (Relay), 220VAC Supply with LCD Display |
ZEN-20C3DR-D-V2 | ZEN CPU; 12DI (DC) / 8DO (Relay), 24 VDC Supply with LCD Display |
ZEN-20C3DT-D-V2 | ZEN CPU; 12DI (DC) / 8DO (Transistor), 24 VDC Supply with LCD Display |
ZEN Communication Type (can't expansion) | |
ZEN-10C4AR-A-V2 | ZEN CPU; 6DI (AC) / 3DO (Relay), 220VAC Supply with LCD Display |
ZEN-10C4DR-D-V2 | ZEN CPU; 6DI (DC) / 3DO (Relay), 24VDC Supply with LCD Display |
Digital IO Expansion Module | |
ZEN-8E1AR | ZEN Expansions 4DI (AC) / 4DO (Relay), 220VAC Supply |
ZEN-8E1DR | ZEN Expansions 4DI (DC) / 4DO (Relay), 24 VDC Supply |
ZEN-8E1DT | ZEN Expansions 4DI (DC) / 4DO (Transistor), 24 VDC Supply |
Power Supply | |
ZEN-PA03024 | ZEN Power Supply Unit 220VAC / 24VDC; 30W, 1.3A |
Accessories Port | |
ZEN-CIF01 | Connecting Cable RS232; 2M. |
ZEN-ME01 | EEPROM Memory Cassette (For Data Security and Copying) |
ZEN-BAT0 | 1 Battery Unit |
