CP1E-E10D

CP1E-E14D

CP1E-E20D

CP1E-E30D

CP1E-E40D

6 inputs,
4 outputs

8 inputs,
6 outputs

12 inputs,
8 outputs

18 inputs,
12 outputs

24 inputs,
16 outputs

Program capacity

2K steps

Data memory
capacity

2 Kword

High-speed
processing

High-speed counters:10 kHz脳6 inputs

USB

-

-

-

YES

YES

Serial
communications

-

-

-

-

-

Expansion Unit

-

-

-

MAX 3 Unit

MAX 3 Unit

Built-in analog I/O

-

-

-

-

-

CP1E-E

CP1E-E10DR-A

CPU 2K Step; 6DI/4DO AC power supply,relay outputs,

CP1E-E10DT-D

CPU 2K Step; 6DI/4DO DC power supply,transistor (sinking) outputs

CP1E-E10DT-A

CPU 2K Step; 6DI/4DO AC power supply,transistor (sinking) outputs

CP1E-E10DR-D

CPU 2K Step; 6DI/4DO DC power supply,relay outputs

CP1E-E14DR-A

CPU 2K Step; 8DI/6DO AC power supply,relay outputs

CP1E-E14DT-D

CPU 2K Step; 8DI/6DO DC power supply,transistor (sinking) outputs

CP1E-E14DT-A

CPU 2K Step; 8DI/6DO AC power supply,transistor (sinking) outputs

CP1E-E14DR-D

CPU 2K Step; 8DI/6DO DC power supply,relay outputs

CP1E-E20DR-A

CPU 2K Step; 12DI/8DO AC power supply,relay outputs

CP1E-E20DT-D

CPU 2K Step; 12DI/8DO DC power supply,transistor (sinking) outputs

CP1E-E20DT-A

CPU 2K Step; 12DI/8DO AC power supply,transistor (sinking) outputs

CP1E-E20DR-D

CPU 2K Step; 12DI/8DO DC power supply,relay outputs

CP1E-E30DR-A

CPU 2K Step; 18DI/12DO AC power supply,relay outputs

CP1E-E30DT-D

CPU 2K Step; 18DI/12DO DC power supply,transistor (sinking) outputs

CP1E-E30DT-A

CPU 2K Step; 18DI/12DO AC power supply,transistor (sinking) outputs

CP1E-E30DR-D

CPU 2K Step; 18DI/12DO DC power supply,relay outputs

CP1E-E40DR-A

CPU 2K Step; 24DI/16DO AC power supply,relay outputs

CP1E-E40DT-D

CPU 2K Step; 24DI/16DO DC power supply,transistor (sinking) outputs

CP1E-E40DT-A

CPU 2K Step; 24DI/16DO AC power supply,transistor (sinking) outputs

CP1E-E40DR-D

CPU 2K Step; 24DI/16DO DC power supply,relay outputs
